| ular(Continuous), MD, Alarm), Stop |
| Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
| Trigger Events |
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips |
| Video Detection |
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
| Alarm Input |
16 channel |
| Relay Output |
6 channel |
| Playback & Backup |
| Sync Playback |
1/4/9/16 |
| Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
| Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode |
USB Device / eSATA Device / Internal SATA burner/ Network |
| Network |
| Ethernet |
RJ-45 port (10/100/1000M) |
| Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server |
| Max. User Access |
20 users |
| Smart Phone |
iPhone, iPad, Android, Windows Phone |
| Storage |
| Internal HDD |
8 SATA ports (8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB |
| External HDD |
1 eSATA port (Max 4 SATA HDDs), up to 16TB |
| Auxiliary Interface |
| USB |
4 ports (2 Rear), USB2.0 |
| RS232 |
1 port, For PC communication & Keyboard |
| RS485 |
1 port, For PTZ control |
| General |
| Power Supply |
AC100V~240V, 50/60Hz |
| Power Consumption |
45W (Without HDD) |
| Working Environment |
-10°C ~+55°C / 10~90%RH / 86~106kpa |
| Dimension(W×D×H) |
3U, 439.7mm×448mm×133mm |
| Weight |
8KG (Without HDD) |
